Allied Telesis
MC IE GE TX TO SFP DIN RAIL/990-003870-80 IN
2527.41 RON
Pretul include TVA
Stoc epuizat
Cod produs: AT-IMC1000T/SFP-80
Notificare de stoc
Anunta-ma prin email cand produsul revine
in stoc.
Descriere
Extended Networks
The Allied Telesis Industrial Media Converter (IMC) Series is designed to extend the distance of a network by converting data between twisted pair cabling and multi-mode or singlemode fiber-optic cabling. The IMC100 features a 100FX fixed SC fiber port, while the IMC1000 features an SFP port for maximum flexibility.
VLAN Support
Many new backbone switch products now support the industry-standard IEEE 802.1Q specification for Virtual LANs (VLANs) that send extra-long data packets on the network. IMC Series switches are fully compatible with these long packets, enabling them to be used in modern networks. Switches not supporting this feature will discard these extra-long packets, making them unsuitable for modern networks.
Small and Flexible
The small size and dual external power supply inputs of the IMC Series allows them to be used almost anywhere in harsh environmental conditions. Additionally, they can be mounted both on DIN rail (EN50022) or by wall-mount, allowing users to deploy any mix of network conversions required.
The Allied Telesis Industrial Media Converter (IMC) Series is designed to extend the distance of a network by converting data between twisted pair cabling and multi-mode or singlemode fiber-optic cabling. The IMC100 features a 100FX fixed SC fiber port, while the IMC1000 features an SFP port for maximum flexibility.
VLAN Support
Many new backbone switch products now support the industry-standard IEEE 802.1Q specification for Virtual LANs (VLANs) that send extra-long data packets on the network. IMC Series switches are fully compatible with these long packets, enabling them to be used in modern networks. Switches not supporting this feature will discard these extra-long packets, making them unsuitable for modern networks.
Small and Flexible
The small size and dual external power supply inputs of the IMC Series allows them to be used almost anywhere in harsh environmental conditions. Additionally, they can be mounted both on DIN rail (EN50022) or by wall-mount, allowing users to deploy any mix of network conversions required.
Specificatii tehnice
| Porturi & Interfete | Fast Ethernet,Gigabit Ethernet; 10Base-T,1000Base-T; 100Base-X,1000Base-X; Wired |
| Retea & Conectivitate | 10,100,1000 Mbit/s; IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Alimentare | 5.28 W |
| Dimensiuni | 30 mm |
| Greutate | 700 g |
| Culoare | Grey |
| Alte caracteristici | Full,Half; Yes; 1000 Mbit/s; SFP; 1310 nm; Activity,Collision,FDX,Link,Power,Power fail; Metal; IP30; 95 mm; 140 mm; -40 - 75 °C; 5 - 95%; -40 - 85 °C; 0 - 2000 m; RoHS |
