WALL MOUNT MC (10PACK)/990-000537-010

Overview
The AT-WLMT is a simple metal bracket that
allows the majority of Allied Telesis’ range of
standalone media and converters and rate
(bridging) converters to be wall-mounted.

Mounting Option Requirements
The majority of media converters are used to
convert fiber optic connections to copper. Many
installations require these media converters to
be installed in a 19-inch chassis, using a range of
mounting options including AT-TRAY1,AT-TRAY2
and the AT-MCR12. However, other applications
such as Fiber-To-The-Home (FTTH), etc, require
a small un-obtrusive mounting option that can
be discretely placed on a wall or under a table
top.The AT-WLMT was designed to meet this
demand.

Simple Installation
Each AT-WLMT has two circular holes and two
‘key’ slots on the base.The use of the circular
holes allows two countersunk screws to mount
the bracket on a horizontal surface underneath
a table top, whilst the two key slots allow the
bracket to be easily wall-mounted.

Security
Any media converter or rate (bridging) converter
mounted in an AT-WLMT chassis is held securely
in place by means of a locking screw.This ensures
that the media converter is not easily removed,
thus helping to prevent accidental breakage of
the fiber optic cable connected to the device, and
also theft of the actual unit.
